RadioMaster TX16S Mark 2 EdgeTX ELRS 16CH Radio Controller
The best RC controller just got better. RadioMaster TX16S Mark 2 ELRS 16CH Radio controller is a high-quality, cost-effective EdgeTX radio.
Features
- Improved internal circulation and optimized power supply.
- New charge circuitry with integrated reverse-polarity protection.
- Optimized charge IC now allows up to 2.2A internal USB-C charge current.
- Rear-mounted audio jack provided headphone output.
- V4.0 Gimbal improved centring and temperature stability (same circuitry as AG01).
- Optional high/low rear grips are included for improved ergonomics.
- Improved S1/S2 knobs with clear centre detents.
- Redesigned battery cover for improved battery access.
- Retooled body shell with improved fit and finish.
- ExpressLRS version
- EdgeTX as default, supports OpenTX
Specifications
- Size: 287x129x184mm
- Weight: 750g
- Transmission frequency: 2.400GHz-2.480GHz
- Transmitter module: Internal ELRS (SX1280)
- Transmitting power: Internal ELRS: Max 250mw (transmitting power is adjustable)
- Antenna gain: 2db (transmit power adjustable)
- Working current: 400mA
- Working voltage: 6.6-8.4v DC
- Remote control distance:> 2km @ 22dbm
- Radio firmware: EdgeTX
- Module Firmware: Multiprotocol ExpressLRS (ELRS)
- Channels: Up to 16 channels (depending on the receiver)
- Display: 4.3-inch TFT full-colour touch display with a resolution of 480 * 272
- Gimbal: Option 1: V4.0 Hall sensor
- Module Bay: JR-compatible module bay
- Upgrade method: Supports USB-C online / SD card offline upgrade
Includes
- 1x TX16S Mark II Radio Controller (ExpressLRS version)
- 1x 18650 Tray
- 1x USB-C Cable
- 1x Screen Protector
- 1x Pair of flat grips
- 1x Pair of raised grips
- 1x TX16S Key Chain
- 1x RadioMaster 21700 2S 7.4V 37Wh 5000mah Li-ion Battery for TX16S
Supports Edge TX and OpenTX
EdgeTX is installed by default (touch screen enabled).
